SFH220 & SFH240 FRONT MOWER SERVICE MANUAL 2.
DISASSEMBLY AND REASSEMBLY
<Remove of the gear case (LH) ASSY> 1. Remove the blades. 2. Remove the spring pin of the universal joint. 3. Remove the universal joint. 4. Remove the shaft cover. 5. Shift the snap ring both LH and RH (40) to inside, and shift the coupling (39) to remove the joint shaft.
shaft cover
universal joint
Left side
Left side
48
