SCMA54, SCMB60, SSM54 hurting children, animals, by-standers. and damaging nearby trees, buildings, etc.
h. To engage PTO, PTO switch (4) to right and pull it up. i. Turn the throttle lever to the high-speed position to raise engine speed.
a. Start the engine and turn the throttle lever (1) to the intermediate position between the low speed and high-speed positions.
j. A s the HST forward travel pedal is depressed gradually, the front mows to travel.
b. Shift the mower lift lever (2) to the up position to raise the mower deck.
k. The front mower is equipped with a system called "Up-stop" device, which stop the mower blades when the mower deck is lifted up while the front mower is travelling on rugged terrain with the mower PTO. WARNING: ・ The up-stop device is installed to prevent accidents. Never attempt to activate the system by operating the mower lift lever. ・ T he mower blades of the mower deck stopped by this device are subject to turning very slowly even when the mower deck is lifted up, which is very dangerous and may shorten the service life of the drive shaft. CAUTION: ・ P TO restriction mechanism works only while the PTO is working. ・ Before starting to mow, make sure that this mechanism works properly. ・ Be sure to detach the drive shaft before checking the PTO restriction mechanism. ・ Be restricted from lift up the mower deck excessively while the mower blades are rotating. ・ When you want to lift up the mower deck high, switch off the PTO switch. Never attempt to switch on the PTO switch while the mower deck is lift up high. ・ Before starting to mow, make sure that the lift cylinder is set properly. ・ Whenever you encounter with any trouble of the front mower, ask your dealer for repair immediately ・ B e sure to start moving at sufficiently low speeds and increase travelling speed gradually.
FIG. 3-7 c. Release the parking brake. d. Depress the HST forward travel pedal gradually to drive the front mower into the working site. e. Release the HST pedal gradually to stop the front mower. f. Shift the mower lift lever (2) to the down position to lower the mower on the ground. g. Select the mower and blower switch (3) to Center position: Mower/Blower operating mode.
WARNING: ・ The mower blades should be turned only on turf or grassland with the mower deck lowered. IMPORTANT: The radiator screen should be kept clean. Never keep on operating with clogged screens, or the engine may be overheated, which may result in engine seizure. FIG. 3-8 92
