Hard drive Description
Spare part number
120-GB, 5400-rpm
435775-001
80-GB, 5400-rpm
435773-001
Before disassembling the computer, follow these steps: 1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then unplugging the AC adapter from the computer.
4.
Remove the battery (see Battery on page 32).
Remove the hard drive: 1.
Position the computer with the front toward you.
2.
Loosen the two Phillips PM2.5×6.0 screws (1) that secure the hard drive cover to the computer.
3.
Lift the left side of the hard drive cover (2), swing it to the right, and remove the cover. The hard drive cover is included in the Plastics/Hardware Kit, spare part number 448431-001.
4.
Grasp the Mylar tab (1) on the hard drive and pull the hard drive (2) to the left to disconnect it from the system board.
Component replacement procedures
33
