Swing-away lattice 5.3 Checklists for rigging work
– Separate the connection on the left-hand side between section 2 and section 1; p. 5 - 84.
à
– Swing section 1 to the side of section 2;
à p. 5 - 88.
– Establish the Folded connection between section 1 and section 2; p. 5 - 86.
à
– Disconnect the electrical connection between section 2 and section 1; p. 5 - 99.
à
11. For combination C – Disconnect the electrical connection between section 2 and section 3; p. 5 - 97.
à
– Sling lifting gear to sections 1 and 2 together and fasten a guide rope; p. 5 - 4. – Disconnect the connection between section 2 and section 3; p. 5 - 81.
à
– Lift sections 1 and 2 together and set down aside.
5 - 32
3 302 624 en
Lattice extension operating manual GMK5150 / GMK5150L
01.07.2017
