Information Center Electronic Display (DPF Models)

The information center electronic display is located on the right door pillar. It provides the following functionality:

•Displays operational status such as engine RPM, coolant temperature and service hours.

•Displays error fault codes and input/output diagnostic data.

•Configures displays settings.

P. Increase Brightness/Return Button – Used for different functions depending upon screen and context:

•Used to increase display brightness. Corresponds to the symbol on the display screen.

•Used to return to previous screen. Corresponds to the symbol on the display screen.

Q. Decrease Brightness Button – Used to decrease display brightness. Corresponds to the symbol on the display screen.

O. Regen/Return Button – Used for different functions depending upon screen and context:

•Switches to the Regen display mode if the symbol is displayed on the screen. Also initiates DPF regeneration if all appropriate conditions are met.

•Used to return to previous screen. Corresponds to the symbol on the display screen.

R. Regen Inhibit Button (DPF models) – Press for 5 seconds to inhibit DPF reset regeneration. Displays the symbol.

Warning

If the LCD is broken, care must be taken with any leaking fluid. If LCD fluid gets onto your skin, wipe with a cloth and wash the area with mild soap and water. If LCD fluid gets into your eyes, thoroughly rinse your eyes with clean water for several minutes and seek medical assistance. If LCD fluid is swallowed, rinse your mouth thoroughly with clean water, then drink a substantial volume of water and induce vomiting. Then seek medical assistance.

Information Center Electronic Display Symbols

The following table describes symbols used in the information center electronic display.

Note: Values may not display for all parameters, depending upon installed options and equipment.

Table 1: Symbols Descriptions

Symbol Description Symbol Description n/min

Engine crankshaft revolutions per minute.

Accumulated operation time. Time is displayed in hours, and accumulates when the engine is running.

Battery charging circuit voltage.

Real-time fuel consumption rate. Displayed in gallons/hour (SAE) or liters/hour (METRIC).

Display brightness increase. Press button (P, Figure 17) when this symbol is displayed to increase screen brightness.

Display brightness decrease. Press button (Q, Figure 17) when this symbol is displayed to decrease screen brightness.

Coolant temperature.

Diesel Particulate Filter (DPF) regeneration (DPF Models). See “Diesel Particulate Filter (DPF) Regeneration Procedures (DPF Models)” on page55.

Table 1: Symbols Descriptions

Percentage of engine power based on load.

Diesel Particulate Filter (DPF) regeneration inhibit (DPF Models). See “Diesel Particulate Filter (DPF) Regeneration Procedures (DPF Models)” on page55.

Note: Strike-through line through the symbol is displayed in red when DPF regeneration is inhibited.

Ambient engine compartment temperature.

Aftertreatment Error

This icon is used to show that there is an error or fault with emission critical components. Note that there will be engine derate conditions if fault is not fixed in a timely manner.

Diesel Particulate Filter (DPF) regeneration in-progress (elevated temperature). See “Diesel Particulate Filter (DPF) Regeneration Procedures (DPF Models)” on page55.
