TROUBLESHOOTING
Problem Sprayer pressure too high
Cause
Solution
Return hose plugged.
Clean or replace hose.
Wrong agitation value setting.
Open agitation valve slightly until pressure goes to required range.
Return hose plugged.
Clean or replace hose.
Wrong agitation valve setting.
Close agitation valve slightly until pressure goes to required range.
Boom set too high.
Lower boom.
Too windy.
Wait for wind to calm.
Boom is bouncing
Traveling too fast.
Slow down.
Main wing wobbles
Clutch too loose.
Tighten clutch bolts.
Gas shock malfunctioning.
Replace gas shock.
Main wing slams hard into folded or unfolded position.
Gas shock malfunctioning.
Replace gas shock.
Flip wing bounces in transport or field position.
Gas shock malfunctioning.
Replace gas shock.
Hydraulic Swing Wing does not unfold.
Latch is engaged.
Release latch. Clean the area and check hardware if latch continues to stick.
Sprayer pressure too low
High spray drift
TROUBLESHOOTING PAGE 66
