OPERATION CHAIN ROUTING & SPECS 1. Jackshaft Drive Chain 2. Auger Drive Chain 3. Expeller Drive Chain 4. Jackshaft Chain Spring Length - 9-1/2” 5. Auger Chain Spring Length - 13-1/2” - 15” 6. Expeller Drive Chain Deflection - 1/2”-3/4”
ADJUSTABLE EXPELLER SHIELD Both models have a multi-position manual adjust expeller shield to direct material and provide the best possible performance for delivery of material.
1000 RPM DRIVELINES The 2320 and 2326 Manure Spreader can be ordered with an optional factory-installed 1000 RPM driveline. Compared to the 540 RPM units, the 1000 RPM driveline equipped unit has a different combination of drive and driven sprockets, drive chains and a 1000 RPM constant velocity telescoping PTO drive.
AUGER & EXPELLER SPEED OPTIONS Manure Spreaders are factory equipped with drive components selected to provide the best possible performance for processing basic material and manure types available. In certain materials, conveying and spreading performance can be improved by altering the speeds of the auger, the expeller, or both.
-23-
