Section 3: Machine Operation 3.1
Introduction to the machine
Figure 3.1 Front view of the BP1166 BALE PROCESSOR
3.1.2
Operator’s station/controls
Operator controlled items: •
Loading tines, to load the bale. One tractor hydraulic circuit is used to control loading tines. (See section 3.2.6 for more information.)
•
The PTO shaft, which runs the rotor.
•
The bale conveyor chain. Another tractor hydraulic circuit is used to control the bale conveyor’s speed and direction. If the tractor is equipped with a PFC circuit, use it to control the bale conveyor.
Adjustable items:
16
•
The conveyor speed control valve (See section 3.4.2 for more information.)
•
Slug bar setting (See section 3.4.2 for more information.)
•
Deflector settings (See section 3.4.1 for more information.) B P 11 6 6 B A L E P R O C E S S O R
OP E R AT I N G I N S T R U C T I O N S
