Operation - Vibration Operation - Vibration 13
Amplitude/frequency - Changeover There are two settings for the drum vibration, use the switch (13) to select. Turn the knob to the left for low amplitude/high frequency and to the right for high amplitude/low frequency. The amplitude setting must not be changed when vibration is in operation. Switch the vibration off (19) and wait until vibration stops before adjusting the amplitude.
19
Engagement and disengagement of the vibration is made with the switch (19) on the top of the forward/reverse lever.
Fig. Instrument panel 13. Amplitude selector 19. Vibration On/Off
Always switch off the vibration before the roller comes to a standstill. Vibration should not be active when the roller is stationary. This can damage both the surface and the machine.
Driving on difficult surfaces 14
15 Fig. Instrument panel 14. Speed selector, drum 15. Speed selector, rear axle
If the machine becomes stuck and is equipped with two-speed drum drive, set the drive knobs as described below - If the drum spins, turn the drum drive to high and the rear axle to low. - If the tires spin, turn the drum drive to low and the rear axle to high. When the machine has regained grip, set the knobs to their original position.
