Maintenance – As required 8.11.3
Servicing the V-belt Protective equipment: n Working clothes n Safety shoes n Protective gloves 1.
Park the machine safely Ä Chapter 6.4 ‘Parking the machine in secured condition’ on page 59.
2.
Allow the engine to cool down.
3.
Unscrew the V-belt guard (1).
4.
Check condition and tension of V-belt.
1 B-692-0067
Fig. 124
ð Compression measurement: 10 - 25 mm (0.4 - 1.0 in). 5. The V-belt cannot be re-tightened.
Replace the V-belt if it is damaged or if the compression measurement is exceeded Ä Chapter 8.9.1 ‘Replacing the Vbelt’ on page 79.
B-GEN-0122
Fig. 125 6.
Fasten the V-belt guard (1).
1 B-692-0067
Fig. 126
