Maintenance – Annually 5.
Check the oil level. ð The oil level must reach the bottom edge of the level bore.
B-695-0014
Fig. 118 Topping up hydraulic oil and bleeding the hydraulic system
NOTICE! Components may get damaged! – Use only oil of the permitted specification Ä Chapter 8.2.4.1 ‘Hydraulic oil’ on page 72. 6.
Clean the area around the filler plug and unscrew the filler plug.
7.
Press the handle forward against the stop and secure it in this position using suitable means.
B-695-0015
Fig. 119
B-695-0016
Fig. 120
