Maintenance – Annually 7.
Tilt the machine to the opposite side and secure it properly. NOTICE! Components may get damaged! Do not use low-ash engine oils for the exciter shaft housing. Observe filling quantity Ä Chapter 8.3 ‘List of fuels and lubricants’ on page 74.
8.
Fill in new oil.
9.
Stand the machine horizontally and check the oil level.
B-695-0159
Fig. 113
ð Nominal value: Bottom edge of filling/drain bore. 10.
Clean the bleed screw and filling/drain plug and screw them in with a low-strength sealing agent (e.g. spare parts number: DL 009 700 16).
11.
Dispose of oil in line with environmental regulations.
B-695-0158
Fig. 114
94
DRP15X
