Maintenance – As required 4.
Check condition and tension of V-belt. ð Compression measurement: 5 - 15 mm (0.2 - 0.6 in).
5. The V-belt cannot be re-tightened.
Replace the V-belt if it is damaged or if the compression measurement is exceeded Ä Chapter 8.8.5 ‘Replacing the Vbelt’ on page 88.
B-GEN-0122
Fig. 139 6.
Fasten the V-belt guard (1).
1 B-692-0151
Fig. 140
8.10.5
Checking the oil level in the exciter housing NOTICE! Components may get damaged! – Use only oil of the permitted specification Ä Chapter 8.3 ‘List of fuels and lubricants’ on page 74. Protective equipment: n Working clothes n Safety shoes n Protective gloves
104
1.
Drive the machine onto horizontal, level, firm ground.
2.
Park the machine safely Ä Chapter 6.5 ‘Parking the machine in secured condition’ on page 61.
3.
Allow the machine to cool down.
DRP15X
