Agroplus 67 77 87 Section: LIGHTING SYSTEM
SUBAS: 84
Ref. 347
ELECTRIC STARTING SYSTEM INSTALLATION ELECTRIQUE DE DEMARRAGE ELEKTRISCHES ANLAßSYSTEM Fig Part Nr Renewal time (d/h)
3 4
Qty
Description
Dénomination
Bezeichnung
2.6519.029.0 1 2.7099.320.0/10 1
cap pressure switch
capuchon contacteur
haube oeldruckschalter
2.8419.007.0 1
horn
avertisseur sonore horn
2.1499.057.1 2.1011.105.2 0.164.8450.0 2.7099.940.0 2.1560.008.0 2.6519.033.0 0.008.0378.0 0.008.0616.0 0.008.0391.0
washer (8.2x23) rondelle elastique nut (m 8 p.1.25) ecrou terminal cosse pressure switch (0.4 - 0.7 BAR)contacteur gasket (12.2x18) joint cap capuchon cover couverture pipe fitting raccord cover couverture
- T. = 0.1 5 - T. = 0.1 6 7 8 9 10 11 12 13 14
1 1 1 1 1 1 1 1 1
elastiche scheibe mutter anschlussklemme oeldruckschalter dichtung haube deckelplatte anschluss deckelplatte
- T. = 0.3
307.6056.3.6
Sheet 1 F
