POWER-LIFT ELECTRONIC SYSTEM

STEERING ROD - MECH. STEERING - TELESCOPIC AXLE

BARRE DE DIRECTION - DIRECTION MECANIQUE - ESSIEU TELESCOPIQUE LENKSTANGE - MECH.LENKUNG - TELESKOPACHSE

Fig Part Nr Qty Description Dénomination Bezeichnung Renewal time (d/h)

1 0.010.0488.4/10 1 joint

- T. = 0.7 -> (0.5 + 0.2 [Cod. 0901])

2 0.900.0025.7 1 *guard 3 0.900.0025.8 1 *nut rotule gelenk

protection abschirmung ecrou mutter

CONDENSER

CONDENSATEUR KONDENSATOR

Fig Part Nr Qty Description Renewal time (d/h) Dénomination Bezeichnung

1 0.014.8525.4 1 condenser 2 0.010.0618.4 1 *fan condensateur kondensator ventilateur ventilator

- T. = 0.5

3 0.900.0462.0 1 *duct

convoyeur luefterhaube 4 0.010.2261.0 1 *filter filtre filter 5 0.900.0304.1 1 *pressure switch contacteur oeldruckschalter

FAN PARTS

PIECES DU VENTILATEUR TEILE DES LÜFTERRADS

Fig Part Nr Qty Description Renewal time (d/h) Dénomination Bezeichnung

1 0.011.1961.4/30 1 condenser 2 0.011.1961.4/30 1 *condenser

condensateur kondensator condensateur kondensator 4 0.010.2261.0 1 *filter filtre filter 5 0.010.2262.0 1 *pressure switch contacteur oeldruckschalter 6 0.010.2545.2 2 *fan ventilateur ventilator

- T. = 1.0

- the time indicated refers to each unit - le temps indiqué se réfère à l'unité - die angegebene Zeit bezieht sich auf die Einheitsmenge

7 0.010.2148.2 2 *washer (6x12) rondelle dichtscheibe 8 0.900.0062.0 1 *tube 9 0.010.2546.1 1 *tube tuyau schlauch tuyau schlauch

10 0.010.2546.2 1 *bracket

etrier buegel 11 0.010.2547.0 5 *bushing (m 5) bague lagerbuchse 12 2.1310.002.3 4 *flat washer (6.4x12x1.6) rondelle plate unterlegscheibe 13 0.010.2547.2 10 *washer (5x11) rondelle dichtscheibe 14 0.010.2548.0 1 *spacer (6.5x15x5) entretoise zwischenrohr 15 0.010.2548.1 4 *washer (5x14) rondelle dichtscheibe 16 0.010.2548.2 9 *nut (m 5) ecrou mutter 17 2.0112.005.2 13 *screw (m 6 p.1x16) vis schraube 18 0.010.2549.1 2 *screw (m 6x40) vis schraube 19 0.010.2549.2 1 *condenser condensateur kondensator

- T. = 3.0 -> (2.0 + 1.0 [Cod. 1001])

HEATER PARTS

PIECES APPAREIL DE CHAUFFAGE TEILE DES BEHEIZERS

Fig Part Nr Qty Description Renewal time (d/h) Dénomination Bezeichnung

1 0.010.8108.4/10 1 heater 2 0.010.2153.1 1 *box 3 0.010.2119.2 25 *screw (4x12) 4 0.010.2120.0 1 *cover 5 0.010.3136.0 1 *blower 6 0.010.2120.2 2 *small spring 7 0.010.2121.0 4 *tongue 8 0.010.2121.1 1 *fan 9 0.010.2121.2 1 *spring 10 0.010.2122.0 1 *resistance 11 0.010.2126.1 1 *gasket 12 0.010.2153.0 1 *radiator chauffage heizungsanlage boitier gehaeuse vis schraube couvercle deckel diffuseur luftduese ressort feder goulot stutzen ventilateur ventilator ressort feder resistance widerstand joint dichtung radiateur radiator

- T. = 6.0

13 0.010.2152.2 1 *gasket 14 0.010.2152.1 1 *gasket 15 0.010.2152.0 1 *tube 16 0.010.2151.2 4 *clamp 17 0.010.2151.1 1 *cock or tap 18 0.010.2151.0 1 *bracket 19 0.010.2150.2 1 *screw joint dichtung

joint

dichtung tuyau schlauch collier schlauchklemmen robinet hahn etrier buegel vis schraube

20 0.010.2150.1 1 *washer 21 0.010.2150.0 1 *rod 22 0.010.2149.2 1 *brace 23 0.010.2149.1 1 *small block 24 0.010.2149.0 1 *nut rondelle scheibe tirant zugstange agrafe klammer bloc einstell-block ecrou mutter

25 0.010.2148.2 1 *washer (6x12) 26 0.010.2148.1 1 *regulator 27 0.010.2148.0 1 *bushing 28 0.009.4743.1 1 *switch 29 0.010.2123.1 2 *nut rondelle dichtscheibe regulateur regler bague lagerbuchse interrupteur schalter ecrou mutter

30 0.009.4743.0 1 *knob pommeau knopf

31 0.009.4743.2 1 *knob

pommeau knopf 32 0.010.2119.0 1 *box boitier gehaeuse 33 0.010.2147.2 1 *electrical system inst.electrique elektr.anlage
