Agroplus 67 77 87 Section: GEAR
SUBAS: 33
Ref. 107
5 SPEED GEARBOX WITH MINI REDUCTION GEAR (- "OVER SPEED") BOITE A 5 VITESSES AVEC MINIREDUCTEUR (- "OVER SPEED") FUENFGANGGETRIEBE MIT MINIKRIECHGANGGETRIEBE (- "OVER SPEED") Fig Part Nr Renewal time (d/h)
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 51 52 56 57 58 59
Qty
2.1410.017.1 6 2.1410.014.1 2 2.2999.114.0 1 2.1499.124.1/10 2 2.2045.011.0 1 0.010.1523.0/10 1 2.2999.271.0 1 2.1559.314.0/10 1 2.2999.336.0/10 1 2.1599.743.0 1 2.1599.744.0 1 2.1599.745.0 1 2.1599.746.0 1 2.1499.123.1/10 2 2.2999.173.0 1 2.1423.026.7 1 2.1410.020.1 1 2.2043.014.0 1 2.1410.020.1 1 2.1599.426.0 1 2.2041.017.0 1 0.013.3437.0/40 1
Description
Dénomination
Bezeichnung
circlip (42) circlip (35) bearing (35x72x17) circlip (68x1.7) ball bearing (35x72x17) ring roller cage (47x55x28) spacer (42x47x30) bearing (42.025x90x23) shoulder (42x62x3.1) shoulder (42x62x3.2) shoulder (42x62x3.3) shoulder (42x62x3.4) circlip roller cage (23x35x16.2) snoulder (35x1.5) circlip (50) ball bearing (50x90x20) circlip (50) snoulder (50x60x2.5) bearing (50x90x20) support
anneau elastique sicherungsring anneau elastique sicherungsring roulement lager anneau elastique sicherungsring roulement a billes kugellager anneau ring cage a rouleaux lager gitter entretoise zwischenrohr roulement lager epaulement schulterlager epaulement schulterlager epaulement schulterlager epaulement schulterlager anneau elastique sicherungsring cage a rouleaux lager gitter anneau d'epaulement distanzring anneau elastique sicherungsring roulement a billes kugellager anneau elastique sicherungsring anneau d'epaulement distanzring roulement lager support halter
- T. = 23.2 -> (3.0 + 20.2 [Cod. 0213]) 60 61 62 63 64 65 66 68
307.6056.3.6
2.0312.326.2 4 2.2999.467.0 1 2.1410.022.1 1 2.0312.220.2 2 2.1549.586.0 1 2.2030.012.0 1 2.1475.003.7 4 0.013.9121.0/10 1
screw (m 10 p.1.5x100) roller bearing circlip (55) screw (m 8 p.1.25x70) spacer ball bearing (55x90x18) washer (10.5x20) plate
vis schraube roulement a rouleaux rollenlager anneau elastique sicherungsring vis schraube entretoise zwischenrohr roulement a billes kugellager rondelle dichtscheibe plaque platte
Sheet 2 F
