6 — PROGRAMMER OPERATION
6
PROGRAMMER OPERATION The universal Curtis PMC handheld programmer (optional) allows you to program, test, and diagnose Curtis PMC programmable controllers. The programmer is powered by the host controller, via an RJ11 modular connector located in the adjustment panel on top of the controller (1207 models) or via a 4-pin Molex connector on the front panel (1207A models). When the programmer is first plugged into the controller, it displays the controller’s model number, date of manufacture, and software revision code. Following this initial display, the programmer displays a prompt for further instructions.
+ + CURTIS PMC + + + + ++++++++++++++++++++
A 4-line LCD display is presented in this window
The LED in the corner of the key lights up to identify the mode of operation
PROGRAM
Scroll the 4-line display (up and down) with these two keys
TEST
SCROLL DISPLAY
MORE INFO
A DIVISION OF CURTIS INSTRUMENTS INC.
Curtis PMC 1207/1207A Manual
DIAGNOSTICS
CHANGE VALUE
Choose the Program, Test, or Diagnostics Mode with one of these three keys
Change the selected item’s value (up or down) with these two keys Get more information about selected items with this key. Also, use this key in combination with other keys to put the programmer in Special modes.
