5 - ASSEMBLY
6. On the top of the main control valve insert the two straight connectors (1). NOTE: O-rings shown are part of the connectors.
RAIL12WEL1333AA
6
RAPH12WEL1281BA
7
RAPH12WEL1281BA
8
7. Insert the straight connector (A) then the 90° elbow (B) on each side of the valve block. Turn the elbow to face toward the rear of the machine.
8. Attach the right pilot spool hose (P) with the yellow and white ties, to the 90° elbow on the right side of the valve block. 9. Attach the left pilot spool hose (Q) with the red and white ties, to the 90° elbow on the left side of the valve block.
12 EN
