5 - ASSEMBLY

5 - ASSEMBLY Install

Kit installation 1. Preassemble the valve block. Insert the anti-cavitation valves (16) into the valve block (14).

NOTE: the block valve may come assembled with the anticavitation from the factory.

RAPH12WEL1277AA

1

RAPH12WEL1295BA

2

2. Remove the bolt and washer from the underside of the loader valve bracket. Save the bolt and washer.

10 EN
