4 - ASSEMBLY
23. Insert the electric cable (21) in the lower part of the side panel (L) and route it through the hole (M).
RAIL16TLB0398AA
18
RAIL16TLB0275AA
19
24. Fasten the plate (22) to the connector on the harness (21). 25. Install the plate (22) onto the side panel (L) with the screws (2). 26. Connect the other connector from harness (21) to the harness of the cab by letting it pass through the lead on the floor. 27. If removed, install the side panel (L) and the floor mat (Y).
28. Connect the hammer control pedal (9) by plugging it into the newly installed connector on the side panel
14 EN
