3 - PRE-ASSEMBLY
8. Repeat the steps 6 and 7 for the right-hand side of the machine.
5
SS14H010
Wheel fenders and cab panels removal WARNING Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity. Always support units or parts with suitable slings or hooks. Make sure the work area is clear of all bystanders. Failure to comply could result in death or serious injury. W0398A
9. Remove the sixteen bolts (H) with the relevant washers and nuts. 10. Remove the two rear wheel fenders (E) from the rear axle.
LEIL16GRD0131BB
6
9 EN
