3 - PRE-ASSEMBLY
Engine hood removal WARNING Heavy objects! Lift and handle all heavy components using lifting equipment with adequate capacity. Always support units or parts with suitable slings or hooks. Make sure the work area is clear of all bystanders. Failure to comply could result in death or serious injury. W0398A
3. From the cab, release the engine hood, and open it. NOTE: if the Bowden cable is faulty, the hood can be released on the left-hand side of the vehicle using a hook.
SS12D526
2
SS14E235
3
SS14H011
4
4. Secure the hood with suitable lifting gear and open it. 5. Disconnect the rearview camera wire harness (if machine is equipped with a rearview camera).
6. Remove the screw (A) on the sliding rod and the hexagon nut (B) on the gas-operated strut. 7. Remove the two screws (C) that fix the hood to the rear frame and put the plate (D) aside.
8 EN
