5 - ASSEMBLY
10. Install the joystick steering LS hydraulic hose (17) to the straight connector (24). 11. Install the JSS pressure hose (19) to the 90° elbow (3). 12. Install the tank hydraulic hose (18) to the 90° elbow (4). 13. Install the joystick steering hydraulic tube (48) to the 90° long elbow (47). 14. Install the cylinder hydraulic hose (45) to the 45° elbow (41). 15. Install the cylinder hydraulic hose (44) to the 45° elbow (41).
LEIL19WHL0727GB
4
14 EN
