5 - ASSEMBLY
10. Install the joystick steering LS hydraulic hose (19) to the straight connector (24). 11. Install the JSS pressure hose (12) to the 90° elbow (2). 12. Install the tank hydraulic hose (18) to the 90° elbow (3). 13. Install the joystick steering hydraulic tube (44) to the 90° long elbow (43). 14. Install the cylinder hydraulic hose (46) to the 45° elbow (42). 15. Install the cylinder hydraulic hose (45) to the 45° elbow (42).
LEIL19WHL0757GB
4
14 EN
