5 - ASSEMBLY
13. Install the joystick steering right hydraulic hoses (22) to the 90° elbows (37). 14. Install the cut-off pilot tank hydraulic hose (24) to the 90° elbow (32). 15. Install the cut-off pilot pressure hydraulic hose (23) to the 90° elbow (30) and the 45° elbow (35). 16. Install the return manifold hose (10) to the straight connector (28). 17. Install the priority valve JSS hose (12) to the 90° elbow (33). 18. Install the priority valve joystick LS hose (13) to the connector (16).
14 EN
