5 - ASSEMBLY
10. Install the 90° elbow (32) on the DR port and the 90° elbow (30) on the P port of the JSS cut-off valve (21). 11. Install the 90° elbow (31) on the C1 port and the straight connector (27) on the C2 port of the JSS cut-off valve (21). 12. Install the 90° elbows (37) to the 90° elbow (31) and the straight connector (27).
LEIL20WHL0444GB
4
13 EN
