OPERATION ADJUSTING THE STEERING COLUMN AND JOYSTICK MOUNTING Steering column adjustment A To adjust the angle of the steering column: Pull lever upwards and position steering column to the required angle, release lever. B To adjust the height of steering column: Push lever downwards and pull/push steering wheel into required position, release lever.
Joystick mounting adjustment Mounting is adjustable both for height and lateral movement. Locate the two 8mm Nyloc nuts mounted on far side of the joystick pod and using a 13mm spanner, slacken nuts, adjust position and re-tighten.
1.5
