1.4
CONTROLS
ADJUSTING THE SEAT Seat(s) Vehicles are provided with either 'Standard suspension' or 'Air suspension' extra comfort seats. Ample adjustment is possible to give a comfortable ride whilst operating most controls. Do not adjust the seat when the vehicle is in action.
1 Fore and aft position Pull lever (A) upwards to release and slide seat forward or backwards to required position. Release lever to lock seat in position. 2 Standard suspension and height adjustment Operator must be seated for adjustment. Fold out handle (B), rotate left to raise the seat and right to lower the seat. Check ride indicator (G) shows green, if red readjust height. Within the band of the ride indicator there is 75mm of height adjustment for any driver. 3 Air suspension and height adjustment Operator must be seated for adjustment. Use lever (J) to adjust, pull to raise, press down to lower. Check ride indicator (G ) shows green, if red readjust height. Within the band of the ride indicator there is 75mm of height adjustment for any driver. 4 Arm rest To adjust height of arm rest (C), rotate roller (D). Arm can also be pivoted from horizontal to vertical position. 5 Back rest adjustment To adjust angle of back rest operator should be seated. Pull lever (E) upwards and lean forwards or backwards until desired position is obtained, release lever (E) to lock back rest in position. 6 Upstop control Both seat types are provided with a variable upstop control (F) to limit upward travel of the suspension. Adjust as indicated on control.
Seat belt
7 Lumber support control Adjust to suit (H), from five selectable positions.
Ensure that the seat belt is always clean, and not frayed or damaged.
Your machine is fitted with a seat belt, the belt must be worn whenever the machine is being operated.
