Drive systems Position all bolts with nuts (8) and if applicable with spacers (9) on the cutter bar contour. Important! Ensure that the correct type of bolt is used (countersunk or cheese-head screw) and that the length is correct. Tighten all bolts or nuts (8) with a torque of 84 ÷ 98 Nm. 22
Install plug (31) with seal (32). Tighten plug (31) with a torque of 30 ÷ 35 Nm. Turn over cutter bar. (Fig. 22) Installing rotor Apply a continuous silicone strip to the contact area of the rotors. Install assembled inlet rotor (42) at the corresponding position in the cutter bar. Important! The drilled holes in the reinforcements are conical. The bolts are inserted from the narrower side of the conical drilled hole.
23 Position front perforated bar (44) with bolts (45). Position rear nuts (8) on the inlet rotor with LOCTITE 243. Note! When the seal has been tested the bolts (45) must be removed again to install the slide. Tighten nuts (8) with a torque of 84 ÷ 98 Nm. Install remaining rotors in the same way as the inlet rotor in their correct relative positions – see page 4.27, Dimensions “cutter bar with 6 cutting discs” and Dimensions “cutter bar with 7 cutting discs” on page 4.28. (Fig. 23)
