Assembly
15
16
17
67930F
2
QUANTUM 6800 S / 5500 S-18 up to 614 0 02242
Assemble brackets (5) with pins (13) and washers, secure with roll pins. First thread the straps (11) of the top plate through the opening in the bracket. Install fill indicators (3) (reed contacts) with 2 screws each. Lay out cables, secure with self-locking straps and connect (ON-ON; OFF-OFF). The top reed contact is connected to the “ON” connection. Pass strap (11) with the sensor magnet through the guides of the bracket and install the sleeve (8) on the top plate with bolt, nut and washers. The sleeve is inserted into the slot in the strap. Install and tension return springs (6). Wind tension ropes (16) (Fig. 2) around the hoops (15) at the rear (Fig. 2) and attach at the front to the hooks (4) of the bracket (5) (Fig. 1). Attach work lights (14) to the outside of each front plate (1). Connect wiring. Raise ladder (12) before moving off. (Fig. 1, 2)
7.2
BA QUANTUM 6800 S / 5500 S-18 / 5500 S-16 / 5500 S / 4500 S - 0299 615.8
