Removing and installing the feed rake Make sure the feeder housing is securely supported. Carefully move the machine backwards. (Fig. 12)
12
Installing the feed rake Carefully move the machine forwards. Insert the bolts (L) on both sides and secure them with nuts. Securely tighten the nuts.
I L
Attach the cutting height indicator (G) and the magnetic pick-up (I). (Fig. 13)
G
13 Setting the magnetic pick-up: Using a valve gauge with a gap measuring 1.5 ± 0.5 mm set the magnetic pick-up (I) and secure into the support using the lock nuts.
I
(Fig. 14)
14 Attach all cutterbar cylinders to the feed rake using bolts (B) and secure using 5 x 32 split pins. (Fig. 15)
B
15
5.4
UA Reisdrusch DO 218 - 202 MEGA - 298 977.0
