Removing and installing the feed rake Dimensions for U-piece (Self-sourced) A B C D E F
U
= = = = = =
46 mm 30 mm 38 mm approx. 70 mm 7 mm ∅ 4 mm
(Fig. 4)
4 Unscrew the mounting clip (B) and cable clip (S). Unscrew the electrical cable at (A).
S
(Fig. 5, 6)
B
5
A
6 Unscrew the retainer plate (H). Place the cable and hydraulic hoses down on the operator’s platform. (Fig. 7) H
7
5.2
UA Reisdrusch DO 218 - 202 MEGA - 298 977.0
