Cutterbar trough – Cutter bar Right-hand machine side: – Mount potentiometer (3) completely with bracket and linkage.
5
– Bolt down cable guide (5) and cable clamps (4). 4
– Connect plug to potentiometers (3). (Fig. 15)
3
15 Left-hand machine side: – Mount potentiometer (3) completely with bracket and linkage.
5
– Bolt down cable guide (5) and cable clamps (4).
6 4
– Connect plug of potentiometer (3). – Bolt down guard (6). (Fig. 16) 3 16 Fully retract the VARIO table and let the table lock (2) catch. (Fig. 2)
Adjusting the potentiometer sensing band, see page 3.1.6 Installing the wobble transmission (spare part no. 643 656.1 and spare part no. 643 656.2), see page 4.3.22 Installing the wobble transmission (spare part no. 637 534.0), see page 4.3.35 Installing and adjusting the knife drive belt (40), see page 4.3.2 Installing the crop dividers, see page 2.1.1 Insert feed plates and move the reel tines to working position. Fold up and lock cutterbar cylinder safety locks. Carry out a test run.
