TIC 1.1.3 Key to diagram:
06/07
Quadrant 2100
Overall hydraulic system
1010 1012 1020 1021
Oil tank (baling pressure hydraulic system) Return filter Pressure filter (working hydraulics) Pressure filter (baling pressure hydraulics)
2036 2038 2039
Baling pressure hydraulic system pump (1.5 l/min) Knotter fan pump Knotter fan motor
3007 3031 3034 3036 3042 3068 3079 3084
Bale ejector hydraulic cylinder Pick-up hydraulic cylinder Baling chamber hydraulic cylinder ROTOCUT knives hydraulic cylinder Cutting frame hydraulic cylinder Stand hydraulic cylinder Bale ramp hydraulic cylinder Steering axle locking hydraulic cylinder
4010 4021 4022
Orifice plate (1.5 mm) Restrictor A Restrictor B
5009
Pick-up relief accumulator (45 bar)
6018 6021 6033 6034 6041
Tractor shut-off valve Jack stand / pick-up changeover valve Bale ejector / bale ramp reversing valve System screw Shut-off valve
7006 7032 7034 7063 7117
+5 Pressure relief valve (80 bar) Non-return valve Lock-up valve unit Input pressure balance Knotter fan pressure relief valve (100 bar)
8039 8040 8041 8042
Jack stand quick-release coupling Working hydraulics oil supply quick-release coupling Working hydraulics return line quick-release coupling LS connection, working hydraulics signal
9001 9011
Working hydraulics measuring point (pick-up) Baling pressure measuring point
