Front power take-off Zuidberg Refitting the power take-off housing – Refit the power take-off housing on the front lift. – Smear the fastening screws (1) of the housing with Loctite (273). – Tighten to 13,8 ± 1 daN·m. – Refit the front lift. Refer to section: "J1".
1
Fig. 29
j214r000axion
– Connect the power take-off housing by aligning the mark on the linking arm made upon removal. Important: The linking shaft clams must be aligned. Y326
– Tighten the screws of the linking arm at a torque of 14,7 daN.m. – Connect the hoses (1) of the cooler "1032". – Connect the supply harness of the "Y326" solenoid valve. – Refit the closing plate.
1
Fig. 30
j26r000axion
– Top up the oil of the power take-off housing through the filling hole (1).
3
Quantity of oil: 2,8 litres. To identify the type of oil, refer to the user manual. – Refit the protector (2). – Tighten the screws (3) to a torque of 1,5 daN·m. – Test the power take-off.
2
j215r000axion
Axion 850-810 – 09.2010 – GB
1
Fig. 31
J2.15
