Front power take-off Zuidberg Disassembling the power take-off clutch – Remove the bearing (1) of the clutch.
2
– Use a press and a compression means (2) to compress the clutch mechanism (3). – Remove the circlip (4).
1
4
3
Fig. 10
j28r000axion
– Remove the piston (1). – Remove the springs (2). – Remove the centering pins (3).
1
– Remove the springs (4).
3
4 2 Fig. 11
j28r001axion
– Pull out the counterplates (1). – Pull out the discs (2).
1
2
j28r002axion
J2.8
Axion 850-810 – 09.2010 – GB
Fig. 12
