Speed increaser gearing Description
73 75 A
79 88 81 94
70
326hsm59
Fig. 59
The speed increaser gearing receives engine rotation through the planet-carrier (73). Movement is transmitted to the 4 "Powershift" module by the crown wheel (70) via the shaft (A).
Under action by the piston (81) or elastic washers (88), the planetary (75) engages the casing (94) or input shaft (79). Note: Part dimensioning and number of clutch elements are not representative.
Axion 850-810 Hexashift – 07.2010 – GB
B1.67
