MECHANICAL PART Description
E
3
A
F 1a
1
2
C
B
D 1b
326msm90
Fig. 45
– Speed increaser gearing (1a).
The "Hexashift" module allows to obtain 6 gears under torque, including:
– Model 4 "Powershift" (b).
– 4 with the 4 "Hexashift" module (1b).
The multiplier (1a) is mainly composed of an epicyclic gear train (3) and a brake clutch (F/E).
– 2 with the (1a) multiplier.
The "Hexashift" module is composed of:
The 4 "Powershift" module is mainly composed of 2 epicycloid trains 1 primary train (1), 1 secondary train (2), and 2 brake clutches, (B/A) and (D/C) respectively.
B1.56
Note: Part dimensioning and number of clutch elements are not representative.
Axion 850-810 Hexashift – 07.2010 – GB
