Measurements and checks Checking the accumulator rating pressure Test conditions: – Increase the temperature of the hydraulic circuit until the accumulator reaches 60°C. – Disconnect the accumulator to discharge it hydraulically.
5015
326hsm5b
Fig. 33
Connect tester n° 60 0570 630 6 onto the nitrogen chamber of the accumulator. Apply the checking procedure in the tester manual. The pressure should be 9 bar.
B1.40
Axion 850-810 Hexashift – 07.2010 – GB
