Electronic components Manual piloting law (pedal) Laws for starting using the clutch pedal, solenoid valve power supply applies the manual law. y
3
4
21 bar P2
1
2
P1 x
BOC Z152 60cmsm15
Fig. 16
Description 1 2 3 4
Request of passage under torque. Until the clutch starts slipping. Gear change under actual torque. Gear engaged operating pressure 21b until change request.
P1 Lick pressure (– 1 bar). P2 Locking pressure. x Pedal position. y Pressure.
