Hydraulic source 60 l/min Replacing the RH cover 1
2
Important : Systematically replace all the seals. – Clean the housing and cover gasket faces.
3
– Check the presence of the two centring pins on the cover. – Coat the cover seal face with Loctite (510). Note : Be careful not to obstruct the ducts. – Refit the cover (1), the filter holder (4) and tighten the screws (3) to 12 daNm.
5
– Refit the solenoid valves.
4
– Tighten the screws (2) to a torque of 2,5 daN.m. – Refit the strainer (5).
6
– Connect the hydraulic pipes and hoses. – Check the operation of the electrical components. – If a hydraulic component has been dismantled or replaced, test the hydraulic circuit. Check the seals on the gasket face and the hydraulic connections.
394msm1g
Arion 640-510 – 12.2008 – GB
Fig. 5
E2.5
