02 Transmission and clutch 02 30 Mechanical reducer
Shimming of tapered roller bearings – Fit the bearings (69) and (70), the washer (65) and elastic ring (64) without the shims.
70
– Measure "C" with a set of shims.
69
64 65
– Fit shims of a thickness corresponding to the measured play. Zero play and preload with a tolerance of 0 ± 0,05 mm. If possible, adjust towards the maximum end of this tolerance. For example, if the play measured is 0,82 mm 0,82 – 0,05 = 0,77 0,82 + 0,05 = 0,87 In this example, the thickness of the shims to be installed should be between 0,77 and 0,87 mm (and as close to 0,87 mm as possible).
Adjusting the shafts in the housing
C
326msm8q
Fig. 31
326hsm2t
Fig. 32
– Fit the primary line and reverse gear in the casing. – Position the cover with the corresponding bearing cups. – Measure the play of the two shafts (see next paragraph). – Remove the upper line and the reverse gear pinion. – Fit the secondary line only in the casing. – Measure the play (see next paragraph). – Remove the secondary line.
