GEARBOX INSTALLATION DISASSEMBLY
FIGURE 1: Remove fastening screws from the reduction unit.
FIGURE 2: Disjoin the entire reduction unit from the axle and place it on a bench.
FIGURE 4: Assemble the oil shield plate in line with box plane.
FIGURE 5: Assemble the separating snap ring onto the output shaft.
NOTE: Carefully remove all residue of Loctite from the surfaces.
This side UP
WARNING Personal injury can result when installing snap ring. The appropriate safety equipment must be worn. To avoid injury to your eyes, wear protective glasses during this procedure.
Inner side FIGURE 3: Re-introduce the oil shield plate with oil inlet facing upwards. For more details, see "Integrated gear box p. 79". FIGURE 6: Using a normal tool, push the bearing its seat in the cover. GSM-0016E - 367 Gear Box Service Manual
Dana Incorporated
75
