COUNTER-REVOLUTION SENSOR REPLACEMENT
0,50 - 0,70 mm
FIGURE 1:
FIGURE 4: Screw the counter-revolution sensor untill to the contact with the phonic end disk, then loosen the sensor ½ ¾ turn. Tighten the lock nuts completely.
FIGURE 2: Undo the sensor adjuster screw lock nut and the counter-revolution sensor.
A
FIGURE 3: Replace the counter-revolution sensor if damaged.
NOTE: Clean the sensor reading zone “A” every oil change and every malfunctioning.
