BI620119
Operator’s Manual
Section
22
Electronic Shutdown System SAFETY SHUTDOWN The electronic shutdown system monitors the atmosphere for methane and controls the engine shutdown and will light the appropriate LEDs on the display panel. The following sensors are fitted to the machine: 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11.
Rev. 2
High Methane Shutdown (1.25%) Low Methane Warning (1%) Charge Failure Engine Oil Pressure Scrubber Level 1 Engine Coolant/Hydraulic Oil Level Scrubber Level 2 Engine Coolant Temperature Exhaust Outlet Temperature Run Solenoid Start Fault
FBL-10 LHD/Utility
Shuts engine down Warning light Warning light Shuts engine down Shuts engine down Shuts engine down Shuts engine down Shuts engine down Shuts engine down Warning light Warning light
75
