2 Various setting and adjustment
2-2-16. Battery voltage calibration When you replace the EPS controller, you need to calibrate battery voltage in order to correctly activate the battery indicator.
<Preparation> l Open the battery cover and set the digital tester to measure battery voltage. Apply the positive (+) probe to the positive terminal of the battery. Apply the negative (-) probe to the negative terminal of the battery. l W hen c alibr at ing, t he bat ter y ne e ds to b e f ully c harge d, so sp e c i f ic gr av it y of bat ter y ele c t ro ly te sh oul d b e over 1. 25 at 20 °C.
<How to calibrate voltage> 1. Set the rotary switch (RS) on the EPS controller to "A". 2. Turn on the key switch. The following screen appears.
CDE
l EPS controller
lBattery voltage setting screen
Set RS to "A".
456
AB
23
F01
789
When the rotary switch mode is set to OFF in the service setting,
Press or button for at least button 3 seconds with pressing button first). (Press
215T0329
Battery Voltage (flashes)
3. Set the voltage to the same value as the actual battery voltage measured by the tester.
NOTE
The allowable variance is within ± 0.1 V. lPress lPress
58
button to increase the value. button to decrease the value.
