1 Basic setting

1-2-5. Rotary switch on the EPS controller The rotary switch (RS) on the EPS controller enables you to select the option settings and adjustment screens shown in the table below.

<Rotary Switch (RS) setting> RS

Remarks

MONITORING OK

Displayed when key switch is ON.

Normal monitor screen

Battery discharge indicator, Travel speed, Hour meter, Error, Clock, Calendar

Hour meter check

Shows hour meter counter (Total, Travel, and Hydraulic)

Date / time setting screen

Set date and time

Slow speed mode setting

Set maximum speed in slow speed mode (2, 3, 4, 5, 6, 7, 8, 10, 12 km/h)

Travel mode setting

Select travel mode (Economy, Normal, Power)

Hour meter, odometer, load weight setting

Select meter indication (Hour meter, odometer, load weight)

Display mode setting

Set brightness of the display screen (0-7: back light adjustment)

Neutral (accelerator OFF) regeneration mode setting

Select neutral regeneration mode (Non, Low, Mid, High)

Pitching control

Switch pitching control ON / OFF

1

Monitor symbol setting

Set monitor symbol (STEER, BATT, OIL, LOAD, BRAKE)

2

Forklift model setting

Set the truck model on the travel/hydraulic board

Plugging strength setting

Set plugging (switch back) brake strength (0-32)

Brake strength setting

Set regenerative brake strength (0-32)

Pitching control volume setting

Set pitching control volume (20, 30, 40, 45)

Lift speed limitation 1 setting: Low travel speed

Set lift speed limit (0-32): Travel speed 0 - 5 km/h

Lift speed limitation 2 setting: Middle travel speed

Set lift speed limit (0-32): Travel speed 5 - 10 km/h

Lift speed limitation 3 setting: High travel speed

Set lift speed limit (0-32): Travel speed 10 km/h over

Lift speed 1 setting

Set lift speed 1 (0 - 32 :1st microswitch)

Lift speed 2 setting

Set lift speed 2 (0 - 32 :2nd microswich)

Tilt speed setting

Set tilt speed (0 - 32)

Attachment 1 speed

Set attachment 1 speed (0 - 32)

Attachment 2 speed

Set attachment 2 speed (0 - 32)

Attachment 3 speed

Set attachment 3 speed (0 - 32)

Hydraulic handling

Set hydraulic handling (1 - 8 : Over drive , Reaction adjustment )

5

Language selecting

Select language (Six languages)

6

Option setting

Set optional functions

0

3

4

20

Functions
