1-41 System Operation Section MD6640 Blasthole Drill
BI012721 AUXILIARY CONTROL CONSOLE
AUXILIARY CONTROL CONSOLE
EXTERIOR LIGHTS The two position switch is used to turn the exterior lights ON and OFF.
TRAIL CABLE TRIP PUSH-BUTTON The large mushroom head push-button is used to completely cut power to the entire machine. Pressing the TRAIL CABLE TRIP button will disable power to the drill from its source. CAUTION:
PRESSING THIS BUTTON WHEN ANY DRIVE IS IN MOTION MAY RESULT IN COMPONENT DAMAGE.
