1-21 System Operation Section MD6640 Blasthole Drill
BI012721 MAIN AIR SYSTEMS
The screw compressor is located within the machinery house just forward of the hydraulic pump gearbox. The rotary screw compressor is an oil flooded, single stage twin screw type compressor which has a nominal rating of 3,000 cfm (84.9m3/min), @ 65 psi and a maximum operating pressure of 65 psi.
Air Compressor
