Bucyrus International, Inc. 59HR Blast Hole Drill
CONTROLS - LOCATION AND FUNCTION Regardless of previous experience, the new operator of any machine must become familiar with the location and function of all of the operating controls before he can begin to operate the machine. Since this manual covers all possible controls that could be used on the machine, he should familiarize himself with both this manual and the particular machine being operated. For the purpose of this manual, the operating controls have been divided into three groups, depending upon their location. These three groups are: 1.
Operator’s Console Controls.
2.
Machinery House Controls.
3.
Miscellaneous Controls.
CAUTION:
October 2009
Read and become familiar with this manual before attempting to operate any of the machine controls. Pay particular attention to the caution and warning statements, and any federal, state, local or company safety rules relating to the machine. Failure to be aware of and understand the hazards associated with the operation of the controls may lead to death, personal injury or serious machine damage.
31
Manual No. 10836
